HD-1100 Real Time Dust Monitor

Haz-Dust™ Model HD-1100 is an affordable Real Time Dust Monitor Designed for Industrial Hygiene, Indoor Air Quality and Haz-Mat air monitoring Investigations providing accurate and instantaneous data on airborne particle concentrations, in accordance with the regulatory USA NIOSH method 0600 for lung damaging Respirable particulates. When coupled with the DL-103 data logger, maximum automation is achieved for data collection, statistical analysis, graphs and detailed report generation. Software is completely Windows compatible and easy to use.



  • Survey for OSHA/EPA compliance
  • Monitor dust generation during drilling/excavation operations
  • Locating and ID “Hot Spots”
  • Emergency Response & fugitive emissions compliance
  • Dust collector/ventilation system checks


  • Handheld
  • Easy operation
  • High Sensitivity
  • Rugged Construction
  • Optional Data Logger & Software
  • Specifications

    Display: LCD in mg/m3

    Sensing range: 0.01-200mg/m3

    PM size range: 0.1-50μm

    Analog output: 0-2 volts

    Battery: 6VDC NiMH rechargeable

    Data logger: Optional

    Operating time: >8 hours

    Operating temp: 0°C -50°C

    Weight: 2 lbs

    Dimensions: 9x3x1.5 in.
